Wire gauge amp chart: complete ampacity reference
Wire Gauge Amp Chart: Complete Ampacity Reference
Choosing the correct wire gauge for a given amperage is one of the most critical decisions in any electrical project. Use the wrong size and you risk overheating, voltage drop, tripped breakers, or even a house fire. The wire gauge amp chart below gives you a quick reference based on the American Wire Gauge (AWG) standard and the National Electrical Code (NEC) Table 310.16, which covers the most common copper and aluminum conductors used in residential and commercial wiring.
| AWG Wire Gauge | Wire Diameter (inches) | Copper Ampacity (60°C / 75°C / 90°C) | Aluminum Ampacity (60°C / 75°C / 90°C) |
|---|---|---|---|
| 18 AWG | 0.0403 | 7 / 10 / 14 | N/A |
| 16 AWG | 0.0508 | 10 / 13 / 18 | N/A |
| 14 AWG | 0.0641 | 15 / 20 / 25 | N/A |
| 12 AWG | 0.0808 | 20 / 25 / 30 | 15 / 20 / 25 |
| 10 AWG | 0.1019 | 30 / 35 / 40 | 25 / 30 / 35 |
| 8 AWG | 0.1285 | 40 / 50 / 55 | 35 / 40 / 45 |
| 6 AWG | 0.1620 | 55 / 65 / 75 | 40 / 50 / 60 |
| 4 AWG | 0.2043 | 70 / 85 / 95 | 55 / 65 / 75 |
| 3 AWG | 0.2294 | 85 / 100 / 115 | 65 / 75 / 85 |
| 2 AWG | 0.2576 | 95 / 115 / 130 | 75 / 90 / 100 |
| 1 AWG | 0.2893 | 110 / 130 / 145 | 85 / 100 / 115 |
| 1/0 AWG | 0.3249 | 125 / 150 / 170 | 100 / 120 / 135 |
| 2/0 AWG | 0.3648 | 145 / 175 / 195 | 115 / 135 / 150 |
| 3/0 AWG | 0.4096 | 165 / 200 / 225 | 130 / 155 / 175 |
| 4/0 AWG | 0.4600 | 195 / 230 / 260 | 150 / 180 / 205 |
Always follow NEC guidelines and local building codes when selecting wire sizes. The ampacity values listed assume no more than three current-carrying conductors in a raceway or cable at an ambient temperature of 30°C (86°F). Derating is required for higher temperatures or bundled conductors. When in doubt, consult a licensed electrician.
What Is Wire Gauge?
Wire gauge is a standardized measurement system that indicates the physical diameter of an electrical conductor. In North America, the American Wire Gauge (AWG) system is the standard. The key concept to remember is that AWG numbers work in reverse: a smaller gauge number means a larger wire diameter, and a larger wire can carry more current.
| Key Concept | Details |
|---|---|
| Standard used | American Wire Gauge (AWG) |
| Numbering direction | Lower number = thicker wire |
| Common residential range | 14 AWG to 4/0 AWG |
| Governing code | NEC Table 310.16 |
For example, a 14 AWG wire has a diameter of about 0.0641 inches, while a 4/0 AWG wire has a diameter of 0.4600 inches. That difference in size directly translates to how much electrical current (measured in amps) the conductor can safely handle.
The AWG system originated in the 1850s and is based on the number of drawing steps required to produce a given wire diameter. Each step reduces the wire's cross-sectional area by roughly 26%, which means every three gauge steps approximately doubles the cross-sectional area and ampacity.
What Is Ampacity?
Ampacity is the maximum amount of electrical current a conductor can carry continuously without exceeding its temperature rating. It is measured in amperes (amps). Exceeding a wire's ampacity generates excess heat, which degrades insulation and creates fire hazards.
| Factor | Effect on Ampacity |
|---|---|
| Wire material (copper vs. aluminum) | Copper carries 15% to 30% more current than same-size aluminum |
| Insulation temperature rating | Higher rated insulation allows higher ampacity |
| Ambient temperature | Temperatures above 30°C require derating |
| Number of conductors in conduit | More conductors = lower ampacity per wire |
| Wire length (voltage drop) | Longer runs may require upsizing wire gauge |
Ampacity values are not fixed for a wire gauge; they change based on the insulation type wrapped around the conductor. The three most common temperature ratings are 60°C (TW insulation), 75°C (THW, THWN), and 90°C (THHN, XHHW-2). Higher temperature-rated insulation allows the same wire gauge to carry more current.
Copper Wire Gauge Amp Chart
Copper is the most widely used conductor in residential and commercial electrical work because of its excellent conductivity, durability, and flexibility. Below is a detailed ampacity chart for copper conductors based on NEC Table 310.16.
| AWG Gauge | 60°C (TW, UF) | 75°C (THW, THWN, XHHW, USE) | 90°C (THHN, THWN-2, XHHW-2) | Typical Breaker Size |
|---|---|---|---|---|
| 14 AWG | 15 amps | 20 amps | 25 amps | 15 amps |
| 12 AWG | 20 amps | 25 amps | 30 amps | 20 amps |
| 10 AWG | 30 amps | 35 amps | 40 amps | 30 amps |
| 8 AWG | 40 amps | 50 amps | 55 amps | 40 amps |
| 6 AWG | 55 amps | 65 amps | 75 amps | 55 to 60 amps |
| 4 AWG | 70 amps | 85 amps | 95 amps | 70 to 80 amps |
| 3 AWG | 85 amps | 100 amps | 115 amps | 85 to 100 amps |
| 2 AWG | 95 amps | 115 amps | 130 amps | 95 to 100 amps |
| 1 AWG | 110 amps | 130 amps | 145 amps | 110 amps |
| 1/0 AWG | 125 amps | 150 amps | 170 amps | 125 to 150 amps |
| 2/0 AWG | 145 amps | 175 amps | 195 amps | 150 amps |
| 3/0 AWG | 165 amps | 200 amps | 225 amps | 200 amps |
| 4/0 AWG | 195 amps | 230 amps | 260 amps | 200 amps |
Even though 14 AWG copper with 75°C insulation has an ampacity of 20 amps, the NEC limits 14 AWG circuits to a maximum 15-amp breaker. Similarly, 12 AWG is limited to a 20-amp breaker. These overcurrent protection limits (NEC 240.4(D)) are separate from ampacity ratings and always take priority for branch circuit wiring.
Aluminum Wire Gauge Amp Chart
Aluminum wire costs less than copper and weighs about 60% less, making it common for service entrance cables, feeder circuits, and large branch circuits. However, aluminum has lower conductivity than copper, so you need a larger gauge aluminum wire to carry the same amperage as a copper conductor.
| AWG Gauge | 60°C (TW, UF) | 75°C (THW, THWN, XHHW) | 90°C (THHN, XHHW-2) | Typical Use |
|---|---|---|---|---|
| 12 AWG | 15 amps | 20 amps | 25 amps | Light branch circuits |
| 10 AWG | 25 amps | 30 amps | 35 amps | Branch circuits |
| 8 AWG | 35 amps | 40 amps | 45 amps | Subpanels, dryers |
| 6 AWG | 40 amps | 50 amps | 60 amps | Large appliances |
| 4 AWG | 55 amps | 65 amps | 75 amps | Feeders, ranges |
| 3 AWG | 65 amps | 75 amps | 85 amps | Feeders |
| 2 AWG | 75 amps | 90 amps | 100 amps | Service entrance, feeders |
| 1 AWG | 85 amps | 100 amps | 115 amps | Service entrance |
| 1/0 AWG | 100 amps | 120 amps | 135 amps | 100-amp service entrance |
| 2/0 AWG | 115 amps | 135 amps | 150 amps | Large feeders |
| 3/0 AWG | 130 amps | 155 amps | 175 amps | 150-amp service |
| 4/0 AWG | 150 amps | 180 amps | 205 amps | 200-amp service entrance |
A general rule of thumb when substituting aluminum for copper: go up two wire gauge sizes. For instance, if a circuit calls for 10 AWG copper, use 8 AWG aluminum to achieve a similar ampacity.
Aluminum wire also requires anti-oxidant compound at connections and must use connectors rated for aluminum (marked AL-CU or AL). Failing to use proper terminations can lead to overheating at connection points due to aluminum's tendency to oxidize and expand under load.
Common Wire Gauge Uses by Circuit Type
Knowing which wire gauge to use for specific household circuits eliminates guesswork. Below is a quick reference matching common circuit types to the appropriate copper wire size and breaker.
| Circuit / Application | Recommended Copper Wire Gauge | Breaker Size |
|---|---|---|
| Lighting circuits | 14 AWG | 15 amps |
| General outlets | 12 AWG | 20 amps |
| Kitchen / bathroom outlets | 12 AWG | 20 amps |
| Window air conditioner | 12 AWG or 10 AWG | 20 to 30 amps |
| Electric dryer | 10 AWG | 30 amps |
| Electric water heater | 10 AWG | 30 amps |
| Central air conditioner | 8 AWG or 6 AWG | 40 to 60 amps |
| Electric range / oven | 6 AWG | 50 to 60 amps |
| EV charger (Level 2) | 6 AWG or 4 AWG | 50 to 80 amps |
| Subpanel feeder | 4 AWG to 2/0 AWG | 70 to 150 amps |
| 200-amp service entrance (copper) | 2/0 AWG | 200 amps |
| 200-amp service entrance (aluminum) | 4/0 AWG | 200 amps |
Kitchen and bathroom outlets always require 20-amp circuits (12 AWG copper minimum) per NEC code, regardless of the actual load on the circuit. These are considered "dedicated" or "small appliance" circuits because of the high-draw devices commonly used in these areas.
How Insulation Temperature Rating Affects Ampacity
The same physical wire can have different ampacity ratings depending on its insulation. Higher temperature-rated insulation can withstand more heat, allowing the conductor to carry additional current. The three standard ratings referenced in NEC Table 310.16 are 60°C, 75°C, and 90°C.
| Temperature Rating | Common Insulation Types | Where Typically Used |
|---|---|---|
| 60°C (140°F) | TW, UF | Older residential wiring, direct burial (UF) |
| 75°C (167°F) | THW, THWN, XHHW, USE | Most residential and commercial branch circuits |
| 90°C (194°F) | THHN, THWN-2, XHHW-2 | Industrial, conduit runs, high-temperature environments |
There is an important caveat with 90°C insulation. While the wire itself can handle higher temperatures, the NEC generally requires that you size the overcurrent protection device (breaker) based on the 60°C or 75°C column. The 90°C rating is primarily used as a starting point for derating calculations, not to load a wire to its maximum 90°C ampacity in standard installations.
The insulation type is printed directly on the wire jacket. For example, a wire marked "12 AWG THHN" tells you it is 12-gauge with 90°C-rated insulation.
Voltage Drop and Wire Sizing for Long Runs
Ampacity charts assume relatively short conductor runs. For longer distances, voltage drop becomes a significant factor that may require you to upsize the wire gauge beyond what ampacity alone dictates. The NEC recommends keeping voltage drop below 3% for branch circuits and 5% total for the combination of feeder and branch circuit.
| Wire Run Distance (copper, 120V, 20A circuit) | Recommended Minimum Gauge | Approximate Voltage Drop |
|---|---|---|
| Up to 50 feet | 12 AWG | Under 3% |
| 50 to 100 feet | 10 AWG | Under 3% |
| 100 to 150 feet | 8 AWG | Under 3% |
| 150 to 200 feet | 6 AWG | Under 3% |
Voltage drop is calculated using the formula: Vd = (2 x L x R x I) / 1,000, where L is the one-way length in feet, R is the wire resistance in ohms per 1,000 feet, and I is the current in amps. The factor of 2 accounts for the full circuit (hot and neutral conductors).
Excessive voltage drop causes lights to dim, motors to overheat and run inefficiently, and sensitive electronics to malfunction. For circuits powering motors or sensitive equipment, keeping voltage drop under 3% is especially important. This is a key consideration when planning to run electric to a garage, shed, or shop located far from your main panel.
Resistance Values by Wire Gauge
Wire resistance increases as the gauge number gets higher (thinner wire). These values help you calculate voltage drop for specific installations.
| AWG Gauge | Copper Resistance (ohms per 1,000 ft) | Aluminum Resistance (ohms per 1,000 ft) |
|---|---|---|
| 14 AWG | 2.525 | 4.132 |
| 12 AWG | 1.588 | 2.599 |
| 10 AWG | 0.999 | 1.635 |
| 8 AWG | 0.628 | 1.028 |
| 6 AWG | 0.395 | 0.646 |
| 4 AWG | 0.249 | 0.408 |
| 2 AWG | 0.156 | 0.256 |
| 1/0 AWG | 0.098 | 0.161 |
Copper vs. Aluminum Wire
Copper and aluminum each have advantages depending on the application. Copper is the default choice for most residential branch circuits because of its superior conductivity and ease of termination. Aluminum is favored for larger service entrance cables and feeders where material cost and weight are significant factors.
| Property | Copper | Aluminum |
|---|---|---|
| Conductivity | 100% (reference standard) | 61% of copper |
| Weight | Heavier | ~60% lighter |
| Cost per foot (same ampacity) | Higher | Lower (typically 40% to 60% less) |
| Oxidation | Minimal concern | Requires anti-oxidant compound |
| Thermal expansion | Lower | Higher (connections can loosen over time) |
| Flexibility | More flexible in smaller gauges | More rigid, harder to work with |
| Minimum NEC branch circuit size | 14 AWG | 12 AWG |
For a 200-amp residential service entrance, you would use 2/0 AWG copper or 4/0 AWG aluminum. The aluminum option costs significantly less and is lighter, making it the most popular choice for service entrance cables across the United States.
Modern aluminum alloy wire (AA-8000 series) has addressed many of the problems associated with older aluminum wiring from the 1960s and 1970s. These newer alloys are more ductile and resist creep, making them safe when installed with properly rated connectors.
Conductor Derating Factors
The ampacity values in NEC Table 310.16 assume no more than three current-carrying conductors in a raceway or cable at an ambient temperature of 30°C. When conditions differ, you must derate (reduce) the ampacity. Ignoring derating leads to overheated conductors.
| Number of Current-Carrying Conductors | Percentage of Ampacity from Table |
|---|---|
| 1 to 3 | 100% |
| 4 to 6 | 80% |
| 7 to 9 | 70% |
| 10 to 20 | 50% |
| 21 to 30 | 45% |
| 31 to 40 | 40% |
| 41+ | 35% |
Ambient Temperature Correction
Installations in hot environments, such as attics in summer or near industrial heat sources, require temperature correction. The NEC provides correction factors based on the ambient temperature and the wire's insulation rating.
| Ambient Temperature |
|---|
